WE HAVE BEEN BUILDING AND SUPPLYING THIS BRAND OF PUMP FOR MORE THAN 20 YEARS. MADE BY A OEM MANUFACTURERS & SUPPLIERS TO VDO, ACDELCO, FORD USA & OTHERS. MADE TO EXCEED OEM SPECIFICATIONS.
WE OFFER A 3 YEAR 40,000 KM WARRANTY. THIS IS NOT THE CHEAPEST PUMP ON THE MARKET, BUT IT'S THE BEST AFTERMARKET PUMP AVAILABLE.

SUITS COMMODORE, BERLINA, CAPRICE, SENATOR, STATESMAN, GRANGE, MONARO & HSV MODELS INC SS, SV6, SSZ, SV8, CV8, CV8-R, R8, HSV, GTS, HSV COUPE-4, HSV COUPE GTO-V2, HSV COUPE GTS-V2.

PLEASE SEND US YOUR VIN NUMBER IF YOU ARE NOT SURE AND WE WILL CHECK IT FOR YOU.

-SUITS
-WK HOLDEN CAPRICE 7/2003-07/2004 5.7L V8 LS1 FROM VIN NO 4L162085 - ON.
-WK HOLDEN CAPRICE 7/2004-2006 5.7L V8 LS1 GEN3.
-VY COMMODORE SEDAN & WAGON 7/2003-07/2004 5.7L V8 LS1 FROM VIN NO 4L156716 - ON.
-VY HOLDEN CALAIS 7/2003-07/2004 5.7L V8 LS1 FROM VIN NO 4L156716 - ON.
-VY COMMODORE ADVENTRA CX8, LX8 7/2003-07/2004 5.7L V8 LS1 FROM VIN NO 4L156716 - ON.
-VY COMMODORE AVALANCH 7/2003-07/2004 5.7L V8 LS1 FROM VIN NO 4L156716 - ON.
-VY COMMODORE GTS, GTS-R 10/2002-09/2004 5.7L V8 LS1 FROM VIN NO 4L162085 - ON .
-VY MONARO 9/2003-07/2004 5.7L V8 LS1 FROM VIN NO 4L167584 - ON.
-VY HOLDEN SENATOR 10/2002-9/2004 5.7L V8 LS1 AFTER VIN NO 4L156716.
-WK HOLDEN GRANGE 7/2003-9/2004 5.7L V8 LS1 FROM VIN NO 4L162085 - ON.
-WK HOLDEN GRANGE 9/2004-10/2005 6.0L V8 LS2.
-WK HOLDEN GRANGE 1/2006-7/2006 6.0L V8 LS2.
-VZ COMMODORE SEDAN & WAGON 7/2004-2007 3.6L V6 ALOYTEC.
-VZ COMMODORE ADVENTRA 7/2004-2007 3.6L V6 ALOYTEC.
-VZ COMMODORE AVALANCH 7/2004-2007 3.6L V6 ALOYTEC.
-VZ HOLDEN CALAIS 7/2004-2007 5.7L V8 LS1.
-VZ COMMODORE SEDAN & WAGON 7/2004-2007 5.7L V8 LS1.
-VZ COMMODORE ADVENTRA 7/2004-2007 5.7L V8 LS1.
-VZ COMMODORE AVALANCH 7/2004-2007 5.7L V8 LS1.
-VZ COMMODORE CLUBSPORT R8 10/2004-7/2006 6.0L V8 LS2.
-WL HOLDEN STATESMAN 7/2004-2007 3.6L V6 ALOYTEC.
-WK HOLDEN STATESMAN 7/2003-7/2004 5.7L V8 LS1 FROM VIN NO 4L162085.
-WL HOLDEN STATESMAN 7/2004-ON 5.7L V8 LS1.
-WL HOLDEN STATESMAN 2006 6.0L V8 LS2.
-WL HOLDEN STATESMAN 2006 6.0L V8 L76.
-VZ HOLDEN SENATOR 10/2004-7/2006 6.0L V8 LS2.

OUR PART NUMBER: MOD-013.
INTERCHANGEABLE WITH
GENUINE PART NUMBER GM: 92159903, 92181807, 92181830, 92183879.
OTHER PART NUMBERS: EFP-135, EFP-145, EFP-146.

SPECIFICATIONS.
FUEL PUMP PART NUMBER: MOD-023.
PRESSURE & FLOW RATE: 155-LPH AT 3-BAR 43.3-PSI 12.5-V 4-AMPS.
ASSEMBLY HEIGHT: BACE TO FLANGE 315-mm COMPRESSED 260-mm.
ASSEMBLY CAPACITY: POD 500-milliliters.
ASSEMBLY HOSE FITTINGS: Left Returnee (10-mm c-lock). Centre (10-mm c-lock) Fuel out. Right (8-mm c-lock) To charcoal canister.
FUEL GAUGE READINGS: Up-full 40-ohms -+5. Down-empty 255-ohms -+5.

WE CAN ALSO SUPPLY THIS ASSEMBLY WITH A WALBRO 255PLH, 400LPH & 460LPH E85 PERFORMANCE FUEL PUMP FOR PERFORMANCE APPLICATIONS UP TO 750-HP AT AN EXTRA PRICE. FOR MORE DETAILS PLEASE CONTACKT US.

We also sell performance and standard fuel pumps, injectors, coils and many other parts.

For General Enquiries :Customer Support ,technical support and bookings & pickups we are located at Prestige Auto Venue, Auto wholesale Australia, 45 Charles Street, Coburg North, Melbourne Victoria 3058. Always best to call first.

Contact through EBay message. Leave us your details and we will get back to you ASAP.

Warranty. 36 Months or 40,000 km Warranty on Passenger Vehicles.

Payment. We accept : Pay on Pickup, PayPal, Bank Transaction, credit card over the phone from 9 to 5 mon to fri & Money Order as payment methods. Please use your EBay Username as a transaction reference.

Postage. Local Pickup (message for address and pick up times) Domestic : Fixed Rate we use Couriers please, Australia Post( Regular Post)and express. International : POA , Please contact us via EBay for a quote. All items sent with tracking number and insurance.

Fitting services. Available in our modern and well equipped work shop.


For General Enquires :Customer Support ,technical support and bookings

Contact through EBay message

Ph : (61) 03 9.35.4 29.62 BH: 9am to 5pm

Mob: 04.17.30.37.75.

.






SKU MOD-013_4
Brand AWA PARTS
Shipping Weight 3.0000kg
Shipping Width 0.200m
Shipping Height 0.150m
Shipping Length 0.300m
Unit Of Measure ea
